BGP703 LED120-4S/740 DM50 PGR SRT SRB 60 - PHILIPS
Luma gen2 - PHILIPS
Availability:
More items are on the way
Net price:
Net Price:
627.96 € *
+0.08 € WEEE fee
Gross price: 747.37 €
Our offers are addressed exclusively to entrepreneurs. We do not conclude contracts with consumers.
Unit: pcs
*
All prices excl. VAT and excl. Shipping.
Item details
Manufacturer:
PHILIPS
Item No.:
43350
GTIN:
8719514181984
Product family:
Luma gen2 - PHILIPS
Wattage (W):
74
Voltage (V):
220-240
Frequency (Hz):
50-60
Colour Temperature (K):
4000
Light Color:
Neutral White
Colour Rendering Index (Ra):
70
Luminous Flux (lm):
10800
Beam Angle (°):
154-31x54
Life Time (h):
100000
Dimmable:
No
Size (LxWxH in mm):
652x295x245
Ambient Temperature:
-40 … +50°C
IP protection class:
66
Protection Class:
I
Impact protection (IK):
09
Flammability mark:
-
Control interface:
Intern (keine externe Verbindung)
Casing color:
Grau
Casing material:
Aluminiumdruckguss
Mounting method:
Aufsatz
Operating device:
Netzteil mit DALI- und SystemReady-Schnittstelle
Control Gear included:
Yes
Failure rate aver. usage time/°C temp.:
5% (50.000 h / 25 °C)
Color Consistency (SDCM):
=5
Luminous Efficiency (lm/W):
146
Luminous flux decline
aver. usage time/°C temp.:
aver. usage time/°C temp.:
4% (50.000 h / 25 °C)
Max. No. Luminaires Circuit Breaker:
21 (B16) und 35 (C16)
No. Of Poles:
5
Wiring Type:
Abschluss
Cover Material:
Glas, klar
Item description
The Luma gen2 is the latest development of the renowned Luma LED product family, designed as a luminaire family for all applications. This latest generation is characterized by outstanding efficiency and user-friendliness in installation, service and maintenance. It was developed with a clear focus on simplified processes around installation, maintenance and recycling to enable a wide range of applications.
Thanks to the integration of SR interfaces, the Luma gen2 offers future-proof options. These interfaces enable seamless integration into advanced lighting management systems such as InteractCity as well as coupling with existing and future sensors. The design of the first generation is retained, while maintenance is optimized by the innovative plug-and-play GearFlex module. This module combines all electrical components in an easily accessible and replaceable, fully insulated plastic box.
In addition, the Luma gen2 is future-proof thanks to optional SystemReady sockets and state-of-the-art operating devices that enable easy adaptation to technological developments. With the intelligent nameplate, users also have direct access to all relevant documentation and spare parts on site.
The aim of the Luma product family is to offer cities a flexible and easy-to-control lighting system that adapts perfectly to the different lighting requirements of different environments.
Thanks to the integration of SR interfaces, the Luma gen2 offers future-proof options. These interfaces enable seamless integration into advanced lighting management systems such as InteractCity as well as coupling with existing and future sensors. The design of the first generation is retained, while maintenance is optimized by the innovative plug-and-play GearFlex module. This module combines all electrical components in an easily accessible and replaceable, fully insulated plastic box.
In addition, the Luma gen2 is future-proof thanks to optional SystemReady sockets and state-of-the-art operating devices that enable easy adaptation to technological developments. With the intelligent nameplate, users also have direct access to all relevant documentation and spare parts on site.
The aim of the Luma product family is to offer cities a flexible and easy-to-control lighting system that adapts perfectly to the different lighting requirements of different environments.
Application area:
Street, city and exterior lighting
- Street and path lighting
- Pedestrian zones and squares
- Traffic signalling systems and road areas
- Airports, shipyard and harbour facilities
